    Tungsten Carbide Ball Nose Tool High Speed High Hardness Long Service Life

    Ask Lasest Price
    Model Number : HG680
    Brand Name : KTC
    Certification : CCC
    Price : Negotiation
    Delivery Time : 1-35days
    Payment Terms : T/T, L/C,Paypal...
    Supply Ability : 10000pcs/week
    • Product Details
    • Company Profile

    Tungsten Carbide Ball Nose Tool High Speed High Hardness Long Service Life

    Tungsten Carbide Ball Nose Tool High Speed High Hardness Long Service Life



    Specifications


    Ball nose cutters or ball end mills are similar to slot drills, but the end of the cutters is hemispherical. They are ideal for machining 3-dimensional contoured shapes in machining centres, for example in dies and moulds.
    Roughing and finishing end mills are used in a variety of milling applications. They remove heavy material while providing a smooth finish in a single pass. Corner rounding end mills are used for milling rounded edges. They have ground cutting tips that strengthen the end of the tool and reduce edge chipping.


    HG680 high speed and high hardness milling cutter series is made of high-quality European grain tungsten steel material, with bending strength of 4600mpa and grain size of 0.2 μm, which is coated with imported Balzers high-performance composite coating. HG680 milling cutters are with special groove design, are especially suitable for high hard material processing. The service life of cutting tools can meet the requirements of great brands. With high precision quality control, and full inspection, all HG680 series end mills are delivered with 100% qualification rate.


    Raw MaterialK44
    WC88%
    Co12%
    TRS>4600N/mm2
    Hardness>94HRA
    A.O.L50mm-150mm
    Grain size0.2μm
    Upto<HRC65
    Flutes No4F
    CoatingBalzers
    Suitable forSteel,stainless steel,nickel alloy,Titanuim alloy,cast iron,plastic and other materials


    Standard Sizes

    SizeFlute Length of End Mills(mm)
    Flat endBall Nose
    D1*D4*5032
    D1.5*D4*5043
    D2*D4*5054
    D2.5*D4*5065
    D3*D4*5086
    D3*D3*5086
    D3.5*D4*5097
    D4*D4*50108
    D1*D6*5032
    D1.5*D6*5043
    D2*D6*5054
    D2.5*D6*5065
    D3*D6*5086
    D3.5*D6*5097
    D4*D6*50108
    D6*D6*501310
    D6*D6*501512
    D7*D8*601714
    D8*D8*602016
    D10*752520
    D12*753024
    D14*1004528
    D16*1004532
    D18*1004536
    D20*1004540
    Flute Length of Extended End Mills(mm)
    D3*D4*75126
    D4*D4*75168
    D5*D6*751810
    D6*D6*752512
    D8*753016
    D3*D4*100156
    D4*D4*100208
    D5*D6*1003010
    D6*D6*1003012
    D8*D8*1003516
    D10*1004020
    D12*1004524
    D6*D6*1504012
    D8*D8*1505016
    D10*1505520
    D12*1505524
    D14*1506028
    D16*1507032
    D18*1507070
    D20*1507070
